S9110-32X

100G Data Center Switch

S9110-32X

32 x 100G QSFP28 Ports

  • 1 RU, Data Center Spine/Leaf Switch
  • 3.2Tbps switching capacity
  • 32 x 40/100G QSFP28 ports
  • 1 x 1G SFP management port
  • 1 x 100/1000M RJ-45 management port
  • 1 x RJ45 serial console port
  • 1 x USB 3.0 Type-A port
OVERVIEW

The UfiSpace S9110-32X is a high-performance, data center networking white box switch that is designed to address the fast growing segment of the data center switching market and the needs to push service capacity to the next level.

With 32 x 100G QSFP28 ports, the S9110-32X spine and leaf switch utilizes the Broadcom Trident3-X7 silicon to provide intelligent features and structured management for centralized servers to enable high-efficiency Ethernet connectivity for data center services.

These switches deliver performance and intelligence to the network edge in a flexible 1RU form factor that helps reduce infrastructure and administrative costs.

The S9110-32X is the epitome of future networking with a powerful Intel Denverton 4-core processor and high-speed 100G interfaces. It comes with redundant, hot swappable components for convenience, increased availability, reliability and lower costs of maintenance.

For additional information or samples of our S9110-32X, please contact our sales team.

FEATURES
  • High density 100G service interfaces
  • 3.2Tbps switching bandwidth capacity
  • Broadcom Trident3-X7 Silicon
  • Front-to-back and Back-to-front airflow options
  • Flexible and efficient data processing
  • On-chip packet buffers minimize the data latency
  • Enable real-time network status visibility
  • BMC for monitoring and managing equipment health status
  • 1 + 1 hot swappable power supply field replaceable units
  • 2 + 1 hot swappable fan field replaceable units

For additional information or samples of our S9110-32X, please contact our sales team.

SPECIFICATIONS

For additional information or samples of our S9110-32X, please contact our sales team.

Physical
Processor Intel Denverton 4 Core @ 1.6GHz
Memory 8GB DDR4
Storage 64GB SSD
ASIC     Broadcom Trident3-X7 BCM56870
BMC AST2620
Chassis 1RU, 440W x 480D x 43.8H mm (17.32" x 18.90" x 1.72")
Weight: 7.44 kg (16.40 lbs)
Redundancy 1+1 hot swappable power units
2+1 hot swappable fan units
Environmental
Power Specs. AC input: 100 to 240V, 10A
DC input: -40 to -75V, 28A
Typical power: 160 Watts (no transceiver)
Operating Specs. Operating temperature:  0°C to 40°C (32°F to 104°F)
Operating humidity: 5% to 95% (RH), non-condensing
Non-Operating Specs.  Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 5% to 95% (RH), non-condensing
