S9600-72XC

72-Port, 25/100GE Open Aggregation Router

  • High density, Multi-function Aggregation Router with TCAM Option
  • Supports SyncE and IEEE 1588
  • 64 x 25GE SFP28 ports
  • 8 x 100GE QSFP28 ports
  • 2 x 10GE SFP+ management ports
  • 1 x RJ45 serial console port
  • 1 x Micro USB serial console port
  • 1 x 1000 Base-T Ethernet port for Out-of-Band management
  • 1 x USB 3.0 Type-A general purpose port
  • GNSS, 1PPS, 10MHz, and ToD timing ports
OVERVIEW

The S9600-72XC open aggregation router, is a multi-function, disaggregated white box aggregation routing platform with an external TCAM option. It is equipped with Broadcom's Qumran2c merchant silicon and Intel Skylake processor for high capacity routing, better power efficiencies and more buffering within a compact 2RU router. It features 64x25GE and 8x100GE high speed ports with a switching capacity of up to 2.4Tbs.

The S9600-72XC can be deployed at C-RAN hubs to provide 5G fronthaul transport aggregation or be positioned at the backhaul for aggregating BBU pooling. It can also be programmed to be a Broadband Network Gateway (BNG) to enable the next generation broadband network. Equipped with high port density, Class C timing and fully supporting SyncE and IEEE 1588v2, the S9600-72XC is capable of fulfilling the role of any type of network aggregation.

Specializing in 5G Time Sensitive Networking applications, the S9600-72XC complies to the IEEE 802.1CM and can act as an Edge Grand Master (GM) clock. Additionally, it is compatible with high accuracy fronthaul synchronization and timing requirements (ITU-T G.8273.2 T-BC, Class C) to ensure error free operation of 5G and cooperative radio techniques.

For additional information or samples of our S9600-72XC, please contact our sales team.

FEATURES
  • Utilizes UfiSpace timing module for Class C Accuracy
  • Supports SyncE and IEEE 1588v2 (T-GM, T-BC/OC, T-TC, T-TSC)
  • Integrated Stratum 3E OCXO with optional hold over performances
  • Rich timing input/output interfaces: ToD, 1PPS and 10MHz
  • Integrated GNSS receiver with passive or active antenna support
  • 4GB deep buffering
  • Option for including an external TCAM
  • BMC for remote monitoring and management
  • 2 hot swappable power supplies with 1+1 redundancy support.
  • 4 hot swappable fan modules with 3+1 redundancy support.
  • 2 RU compact design, suitable for industry standard 19" racks.

For additional information or samples of our S9600-72XC, please contact our sales team.

SPECIFICATIONS

For additional information or samples of our S9600-72XC, please contact our sales team.

Physical
Processor Intel Skylake-D 8 Core @ 1.9GHz
Memory 2x16GB DDR4 R-DIMM with ECC
Storage 1x128GB SSD
ASIC

Broadcom Qumran2c BCM88820
Broadcom OP2 BCM16K Optional
Chassis 2RU, 436W x 87.7H x 609.6D mm  (17.17"x3.45"x24")
Weight: 23.12 kg (50.86 lbs)
Redundancy 1+1 hot swappable power units
3+1 hot swappable fan units
Environmental
Power Spec. AC input: 200 to 240V
DC input: -40 to -75V
Typical power: 234 Watts (no transceiver)
Operating Spec. Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating humidity: 5% to 85% (RH), non-condensing
Non-Operating Spec.  Storage temperature: –40°C to 70°C (–40°F to 158°F)
Storage humidity: 5% to 95% (RH), non-condensing
Applications

Broadband Network Gateway

Metro Aggregation
