概論

The UfiSpace S9620-40DG is an ultra-compact 40-port open aggregation router built on the Broadcom Qumran3a silicon, specifically engineered for high-density transport in space-constrained environments.

The platform features a versatile port configuration including 24 x 50G SFP56 ports, 12 x 100G QSFP28 ports, and high-speed uplink options of either 4 x 400G or 2 x 800G via QSFP-DD ports. With its industry-leading 250mm depth, this router is optimized for deployment in shallow outdoor cabinets or crowded street-side enclosures where standard rack-mount equipment cannot fit.

The hardware supports MACsec encryption across all ports and is compatible with 400G/800G ZR+ coherent optics for long-reach metro aggregation. This combination of 800G capability and deep-buffer Qumran architecture allows the S9620-40DG to serve as a high-capacity cell site aggregator or a compact DCI edge node, maintaining low latency and packet-loss prevention for jitter-sensitive 5G and AI inference traffic.

特色

• Support 400G/800G ZR and ZR+
• MACsec support on all ports enables extra security
• Class C timing accuracy support
• Supports full SyncE and IEEE 1558v2 (T-GM, T-BC/OC, T-TC)
• Integrated Stratum 3E OCXO with optional hold over performances
• Rich timing input/output interfaces: GNSS, 1PPS, 10MHz, ToD and BITS
• 16GB deep buffering
• Supports Time Sensitive Networking (TSN) for low packet loss and low delay variation
• Supports Intel® MACsec for high-reliability NVMe RAID storage management
• 2 hot swappable power supplies with 1+1 redundancy support
• 5 hot swappable fan modules with 4+1 redundancy suppor
• 2 RU compact design, fit into industry standard ETSI 600mm racks.
• For additional information or samples of our S9620-40DG, please contact our sales team
