32-Port, 400GE 數據中心交換器
- 1 RU, Data Center Spine Switch
- 12.8Tbps switching capacity
- 32 x 400GE QSFP-DD ports
- 2 x 10GE SFP+ management ports
- 2 x10GE SFP+ OOB management ports
- 1 x 10/100/1000 RJ-45 OOB management port
- 1 x RJ45 serial console port
- 1 x USB 3.0 Type-A port
The UfiSpace S9301-32D is a high-performance, data center networking white box switch that is designed to address the fast growing segment of the data center switching market and the needs to push service capacity to the next level.
With 32 x 400GE QSFP-DD ports, the S9301-32D data center switch is where computer resources (servers or blade chassis) are centralized and managed in a structured way utilizing high-efficiency Ethernet connectivity.
These switches deliver performance and intelligence to the network edge in a flexible 1RU form factor that helps reduce infrastructure and administrative costs.
The S9301-32D is the epitome of future networking with a powerful 8-core processor and 32 high-speed 400GE interfaces. It comes with redundant, hot swappable components for convenience, increased availability, reliability and lower costs of maintenance.
- High density 400GE interfaces in 1RU chassis
- 12.8Tbps switching bandwidth capacity
- Broadcom Tomahawk3 Silicon
- Flexible and efficient data processing
- On-chip packet buffers minimize the data latency
- Enable real-time network status visibility
- BMC for monitoring and managing equipment health status
- 1 + 1 hot swappable power supply field replaceable units
- 5 + 1 hot swappable fan field replaceable units
|處理器||Intel Skylake-D D-2145NT 8 Cores @1.9GHz|
|記憶體||2x16GB DDR4 R-DIMM with ECC support|
|ASIC||Broadcom Tomahawk3 BCM56980|
|機箱規格||1RU, 436 x 44.0 x 645 mm (WxHxD), 17.17 x 1.73 x 25.4 in.
Weight: 29 kg (63.9 lbs)
|風扇配置||1+1 hot swappable power units
5+1 hot swappable fan units
|電源供應器||AC input: 200 ~ 240V
DC input: -40 ~ -75V
Max power: 1300 Watts
|操作環境規格||Operating temperature: 0°C to 40°C (32°F to 104°F)
Operating humidity: 10% to 90% (RH), noncondensing
|儲存環境規格||Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 5% to 95% (RH), non-condensing
