S9600-56DX

56-Port, 100/400GE 開放式聚合路由器

  • 400G Multi-function Aggregation Router
  • Supports TSN, SyncE and IEEE 1588
  • 8 x 40/100/400GE QSFP-DD ports
  • 48 x 40/100GE QSFP28 ports
  • 4 x 1/10/25GE SFP28 (MUX configurable from Port-0)
  • 1 x RJ45 serial console port
  • 1 x Micro USB serial console port
  • 1 x 100/1000M RJ45 management port
  • 1 x USB 3.0 Type-A general purpose port
  • GNSS, 1PPS, 10MHz, and ToD timing ports
概論

The S9600-56DX open aggregation router, is a multi-function, white box aggregation routing platform. It is equipped with Broadcom's Qumran2c merchant silicon chip with Intel's Icelake processor. The platform features 48x100G and 8x400G high speed ports with a switching capacity of up to 4.8Tbps.

The S9600-56DX can be deployed at C-RAN hubs to provide 5G fronthaul transport aggregation, positioned at the backhual for aggregating BBU pools or be programmed to be a Broadband Network Gateway (BNG) to enable next generation broadband network. Supporting OpenZR+ makes it an idea solution for metro aggregation.

Specializing in 5G time-critical applications, the S9600-56DX can act as an Edge Grand Master (T-GM) or Boundary Clock (T-BC). Our open aggregation router is compatible with high accuracy fronthaul synchronization and timing requirements to ensure error free operation of 5G and cooperative radio techniques.

For additional information or samples of our S9600-56DX, please contact our sales team.

特色
  • Utilizes UfiSpace timing module for Class C Accuracy
  • Supports SyncE and IEEE 1588v2 (T-GM, T-BC/OC, T-TC, T-TSC)
  • Integrated Stratum 3E OCXO with optional hold over performances
  • Rich timing input/output interfaces: ToD, 1PPS and 10MHz
  • Integrated GNSS receiver with passive or active antenna support
  • 8GB deep buffering
  • BMC for remote monitoring and management
  • 2 hot swappable power supplies with 1+1 redundancy support.
  • 4 hot swappable fan modules with 3+1 redundancy support.
  • 2 RU compact design, suitable for industry standard 19" racks.

For additional information or samples of our S9600-56DX, please contact our sales team.

規格

S9600-56DX的產品各類相關文件或樣品需求,歡迎聯繫我們的銷售團隊

硬體規格
處理器 Intel Icelake-D 8-Core @ 2.1GHz
記憶體     32GB DDR4
儲存技術 128GB SSD
ASIC Broadcom Qumran2c BCM88820
機箱規格 2RU, 436W x 762D x 87.7H mm  (17.17"x30"x3.45")
Weight: 19.3 kg (42.55 lb)
風扇配置 1+1 hot swappable power units
3+1 hot swappable fan units
環境規格
電源規格 AC input: 200 to 240V, 12.5A
DC input: -40 to -72V, 60A
Typical power: 488 Watts (no transceiver)
操作環境規格 Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating humidity: 5% to 85% (RH), non-condensing
儲存環境規格  Storage temperature: –40°C to 70°C (–40°F to 158°F)
Storage humidity: 5% to 93% (RH), non-condensing
