48-Port, 100/400G 開放式聚合路由器
- 400G Multi-function Aggregation Router
- Supports SyncE and IEEE 1588
- 8 x 100/400G QSFP-DD ports
- 40 x 40/100G QSFP28 ports
- 4 x 1/10/25G SFP28 (MUX configurable from Port-0)
- 1 x RJ45 serial console port
- 1 x Micro USB serial console port
- 1 x 100/1000M RJ45 management port
- 1 x USB 3.0 Type-A general purpose port
- GNSS, 1PPS, 10MHz, BITS and ToD timing ports
The UfiSpace S9610-48DX Open Aggregation Router, is a high density and multi-function white box aggregation routing platform. It utilizes the Broadcom Qumran2c+ merchant silicon and Intel Icelake processor to enable high capacity, better power efficiency and more buffering within a compact 2RU router.
The S9610-48DX provides, a switching capacity of up to 7.2Tbps with full support for both SyncE and IEEE 1588v2 timing profiles. With capabilities to act as an Edge Grand Master (GM) clock and support for Class C timing accuracy, the S9610-48DX can play a role throughout the mobile transport network. It features 40 high speed 100G ports with an additional 8x400G ports for backhaul.
The S9610-48DX platform can enable multiple application architectures required for high traffic loading in a both fixed and 5G mobile Ethernet networks such as aggregating BBU pools or even as a Broadband Network Gateway (BNG). Additionally, the 400G ports support OpenZR+ and 400ZR to enable a simpler architecture for optical longhaul transmission.
- Supports OpenZR+ and 400ZR
- Supports SyncE and IEEE 1588v2 (T-GM, T-BC/OC, T-TC, T-TSC)
- Class C timing accuracy
- Integrated Stratum 3E OCXO with optional hold over performances
- Rich timing input/output interfaces: ToD, 1PPS, BITS and 10MHz
- Internal GNSS receiver for master clock implementations
- 8GB deep buﬀering
- BMC for remote monitoring and management
- 2 hot swappable power supplies with 1+1 redundancy support.
- 4 hot swappable fan modules with 3+1 redundancy support.
- 2 RU compact design, suitable for industry standard 19" racks.
|處理器||Intel Icelake-D 12-Core @ 1.8GHz|
|ASIC||Broadcom Qumran2c+ BCM88840|
|機箱規格||2RU, 436W x 762D x 87.7H mm (17.17" x 30" x 3.45")|
|風扇配置||1+1 Hot swappable power units
3+1 Hot swappable fan units
|電源規格||AC input: 200 to 240V, 12.5A
DC input: -40 to -72V, 60A
|操作環境規格||Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating humidity: 5% to 85% (RH), non-condensing
|儲存環境規格||Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 5% to 93% (RH), non-condensing
